Kelford Cams 226-HS Nissan RB30 High Performance Camshaft
Kelford Cams 226-HS Nissan RB30 High Performance Camshaft

Kelford Cams 226-HS Nissan RB30 High Performance Camshaft

by Kelford Cams
$1,022.35 NZD
SKU KC226-HS
Buy now pay later,no extra cost!

Payments from $102.23 with

Enjoy now. Pay Later. Interest free. Learn More
Add to Wishlist

Note: Please check availability with us before ordering.

296/304 Degrees advertised duration, 13.70mm/13.70mm lift.

Additional Information:

Solid lifter cam to suit various high RPM racing applications. Suits well built competition engines with large turbo. Primary lobe specification is / Degrees advertised duration, lift.

Camshaft Specifications:

Engine Make: Engine Model: Part Number:
NISSAN RB30 226-HS
Valve Clearance: Intake: 0.40mm Set COLD at the VALVE
  Exhaust: 0.40mm Set COLD at the VALVE

Cam Lift:   Intake: 8.81mm Exhaust: 8.81mm
Rocker Ratio:   Intake: 1.6 Exhaust: 1.6
Nett Valve Lift:   Intake: 13.70mm Exhaust: 13.70mm
Advertised Duration @ 0.10mm Intake: 296 Exhaust: 304
Duration @ 1.00mm VALVE LIFT Intake: 260 Exhaust: 264
Timing @ 1.00mm VALVE LIFT IVO: 18 BTDC EVO: 70 BBDC
    IVC: 62 ABDC EVC: 14 ATDC
Suggested Centre Lines:   Intake: 112 Exhaust: 118
VALVE Lift @ TDC Intake: 2.69mm Exhaust: 2.15
