Kelford Cams 226-F Nissan RB30 High Performance Camshaft

$1,022.35 NZD
SKU KC226-F
Buy now pay later,no extra cost!

Payments from $102.23 with

Enjoy now. Pay Later. Interest free. Learn More
Add to Wishlist

Note: Please check availability with us before ordering.

274/274 Degrees advertised duration, 12.95mm/12.95mm lift.

Additional Information:

Stage 2 cam to suit street / strip applications. Suits 350-500HP turbo range. Good midrange performance. Primary lobe specification is / Degrees advertised duration, lift.

Camshaft Specifications:

Engine Make: Engine Model: Part Number:
NISSAN RB30 226-F
Valve Clearance: Intake: Set at the
  Exhaust: Set at the

Cam Lift:   Intake: 8.09mm Exhaust: 8.09mm
Rocker Ratio:   Intake: 1.6 Exhaust: 1.6
Nett Valve Lift:   Intake: 12.95mm Exhaust: 12.95mm
Advertised Duration @ 0.10mm Intake: 274 Exhaust: 274
Duration @ 1.00mm VALVE LIFT Intake: 241 Exhaust: 241
Timing @ 1.00mm VALVE LIFT IVO: 10.5 BTDC EVO: 56.5 BBDC
    IVC: 50.5 ABDC EVC: 4.5 ATDC
Suggested Centre Lines:   Intake: 110 Exhaust: 116
VALVE Lift @ TDC Intake: 2.05mm Exhaust: 1.37
