Turbosmart TS-2 Turbocharger 5862 V-Band 0.82 A/R Externally Wastegated
The Turbosmart TS-2 5862 Turbocharger is a high-performance oil and water-cooled, externally wastegated turbocharger designed for fast response and exceptional power delivery in street and motorsport applications. Featuring a 58mm compressor inducer, 62mm turbine exducer, V-Band turbine inlet, and 0.82 A/R turbine housing, it delivers rapid spool, outstanding transient response, and supports 600–750HP. Built with a lightweight 310S stainless steel turbine housing, billet aluminium compressor cover, proprietary dual ceramic bearing system, and a T14 Inconel turbine wheel, it offers outstanding durability and efficiency. Each turbocharger includes weld flanges, V-band clamps, gaskets, oil feed and drain fittings, plus water feed and return fittings for a complete installation.
Features
- Oil and water-cooled TS-2 turbocharger
- Externally wastegated design
- 58mm compressor inducer and 62mm turbine exducer
- V-Band turbine inlet with 0.82 A/R housing
- Lightweight 310S stainless steel investment cast turbine housing
- Billet aluminium compressor cover
- 7+7 splitter wheel compressor design
- T14 Inconel turbine wheel for extreme exhaust temperatures
- Proprietary dual ceramic bearing system
- CFD-optimised housing for improved airflow and response
- VSR speed balanced for smooth, reliable operation
- Integrated iron backplate centre housing
- Includes weld flanges, V-band clamps, gaskets, oil feed and drain fittings, and water feed and return fittings
Specifications
- Compressor Inlet: 4.00" (101.6mm)
- Compressor Inducer: 58mm
- Turbine Inlet: V-Band (2.25")
- Turbine Exducer: 62mm
- Turbine A/R: 0.82
- Turbine Outlet: 3.00" V-Band
- Cooling: Oil and Water Cooled
- Wastegate: External
- Weight: 6.06kg (13.3lbs)
- Horsepower Rating: 600–750HP
