Hondata K-Pro 4
by Hondata
$1,934.75 NZD
SKU HONDATA-KPRO4-Board
Buy now pay later,no extra cost!
Payments from $193.47 with
Enjoy now. Pay Later. Interest free. Learn More
The most advanced K Series tuning option on the market. Used by 1000's world wide and now available at Speed Science!
Only suitable for Type S DC5 and Type R DC5's, EP3's and K-Swap vehicles.
The K-Series Programmable ECU (K-Pro) consists of a hardware modification to any K-Series ECU, plus Windows software which allows you to re-program the ECU and datalog sensors.
Main features:
- Fits inside the ECU
- Designed and assembled in USA
- USB connection for speed and compatibility
- KManager Windows based software for parameter & table editing, calibration uploading, and datalogging.
- Many built in calibrations for common engine combinations
- Built in datalogging to a laptop
- On board datalogging memory (8 MB memory, 10-215 minutes datalogging)
- Adjustment for different sized injectors, with overall fuel trim.
- Configurable for any MAP sensor (to 5 Bar and above)
- TPS based table lookup for ITBs
- Engine protection from lean air fuel ratios, over boost and low oil/fuel pressure.
- Expanded fuel and ignition tables, both in rpm and load, to 60 lbs boost and 11,000 rpm (these are not the upper limits)
- Launch control with anti-lag
- Three multi purpose outputs for nitrous control or similar.
- Supports lambda tracing from the stock wideband o2 or aftermarket wideband.
- PWM output for boost control
- Bluetooth support and Hondata Mobile app.
- Ethanol sensor input for flex-fuel capability.
- Alternate speed sensor input.
- Dash output serial & CAN streams.
- Live tuning and autotune.
PLEASE READ:
- If your ECU (supplied by you) for the installation of the board is found to be faulty there may be additional costs to fix it. we will advise you of this cost before any repair work is undertaken.
- Only PND (From Type S - NZ NEW) and PRC ECU's from DC5 ITR' & NZDM/JDM EP3 CTR are accepted. Contact US if you are unsure whether your ECU is compatible.
- Speed Science is a certified Hondata installer. The K-Pro will not be supplied separately for customer installation.
Please allow 2/3 weeks for shipping and K-Pro Installation. In some cases, we will have pre-installed K-Pro's ready for immediate exchange.
