Kelford Cams KCG20 Nissan SR20 Adjustable Cam Gears
Buy now pay later,no extra cost!
Payments from $49.05 with

Note: Please check availability with us before ordering.
260/266 Degrees advertised duration, 11.80mm/11.00mm lift.
Additional Information:
Street performance cams to suit small turbo upgrade. High lift and low duration for great low end, and midrange power. Require KVS93 valve springs.
Camshaft Specifications:
| Engine Make: | Engine Model: | Part Number: | ||||
| NISSAN | SR20DE/T S14 & S15 NVCS | V-188-A | ||||
| Valve Clearance: | Intake: | Set | at the | |||
| Exhaust: | Set | at the | ||||
| Cam Lift: | Intake: | 7.61mm | Exhaust: | 7.10mm | ||
| Rocker Ratio: | Intake: | 1.55 | Exhaust: | 1.55 | ||
| Nett Valve Lift: | Intake: | 11.80mm | Exhaust: | 11.00mm | ||
| Advertised Duration @ | 0.10mm | Intake: | 260 | Exhaust: | 266 | |
| Duration @ | 1.00mm VALVE LIFT | Intake: | 218 | Exhaust: | 222 | |
| Timing @ | 1.00mm VALVE LIFT | IVO: | 21 ATDC | EVO: | 43 BBDC | |
| IVC: | 59 ABDC | EVC: | 1 BTDC | |||
| Suggested Centre Lines: | Intake: | 130 | Exhaust: | 112 | ||
| VALVE | Lift @ TDC | Intake: | 0.06mm | Exhaust: | 0.92 |
