Kelford Cams KVS1518 Nitrided High Perf Beehive LS Race Spring
Buy now pay later,no extra cost!
Payments from $63.96 with

Note: Please check availability with us before ordering.
272&268/268 Degrees advertised duration. 11.30mm&10.50mm/10.50mm lift.
Additional Information
High lift 272 degree racing camshafts. Requires cylinder head modification to fit. Suits well built competition motors. Good on E85 fuel. Must have shimless buckets and aftermarket ECU.
Camshaft Specifications:
| Engine Make: | Engine Model: | Part Number: | |||||
| SUBARU | 2.5 STI 2005-2006 | R-199-C | |||||
| Valve Clearance: | Intake: | 0.20mm | Set | COLD | at the | CAM | |
| Exhaust: | 0.25mm | Set | COLD | at the | CAM | ||
| Cam Lift: | Intake: | 11.50mm | Exhaust: | 10.75mm | |||
| Rocker Ratio: | Intake: | 1 | Exhaust: | 1 | |||
| Nett Valve Lift: | Intake: | 11.30mm | Exhaust: | 10.50mm | |||
| Advertised Duration @ | 0.25mm | Intake: | 272 | Exhaust: | 268 | ||
| Duration @ | 1.00mm VALVE LIFT | Intake: | 232 | Exhaust: | 228 | ||
| Timing @ | 1.00mm VALVE LIFT | IVO: | 14 ATDC | EVO: | 47 BBDC | ||
| IVC: | 66 ABDC | EVC: | 1 ATDC | ||||
| Suggested Centre Lines: | Intake: | 130 | Exhaust: | 113 | |||
| VALVE | Lift @ TDC | Intake: | 0.12mm | Exhaust: | 1.11 | ||
