Kelford Cams KVS17 Mazda L3 2.3 DISI Beehive Valve Spring Set
Buy now pay later,no extra cost!
Payments from $65.82 with

Note: Please check availability with us before ordering.
292&288/294 Degrees advertised duration. 11.00mm&11.00mm/11.00mm lift.
| Engine Make: | Engine Model: | Part Number: | |||||
| SUBARU | 2.5 STI 2005-2006 | R-199-E | |||||
| Valve Clearance: | Intake: | 0.20mm | Set | COLD | at the | CAM | |
| Exhaust: | 0.25mm | Set | COLD | at the | CAM | ||
| Cam Lift: | Intake: | 11.20mm | Exhaust: | 11.25mm | |||
| Rocker Ratio: | Intake: | 1 | Exhaust: | 1 | |||
| Nett Valve Lift: | Intake: | 11.00mm | Exhaust: | 11.00mm | |||
| Advertised Duration @ | 0.25mm | Intake: | 292 | Exhaust: | 294 | ||
| Duration @ | 1.00mm VALVE LIFT | Intake: | 250 | Exhaust: | 252 | ||
| Timing @ | 1.00mm VALVE LIFT | IVO: | 13 BTDC | EVO: | 64 BBDC | ||
| IVC: | 57 ABDC | EVC: | 8 ATDC | ||||
| Suggested Centre Lines: | Intake: | 112 | Exhaust: | 118 | |||
| VALVE | Lift @ TDC | Intake: | 2.42mm | Exhaust: | 1.85 | ||
