Kelford Cams 226-B Nissan RB30 High Performance Camshaft

$1,022.35 NZD
SKU KC226-B
Buy now pay later,no extra cost!

Payments from $102.23 with

Enjoy now. Pay Later. Interest free. Learn More
Add to Wishlist

Note: Please check availability with us before ordering.

270/270 Degrees advertised duration, 11.30mm/11.30mm lift.

Additional Information:

Stage 2 cam to suit slightly modified engines. Requires ECU re-tune. Primary lobe specification is / Degrees advertised duration, lift.

Camshaft Specifications:

Engine Make: Engine Model: Part Number:
NISSAN RB30 226-B
Valve Clearance: Intake: Set at the
  Exhaust: Set at the

Cam Lift:   Intake: 7.06mm Exhaust: 7.06mm
Rocker Ratio:   Intake: 1.6 Exhaust: 1.6
Nett Valve Lift:   Intake: 11.30mm Exhaust: 11.30mm
Advertised Duration @ 0.10mm Intake: 270 Exhaust: 270
Duration @ 1.00mm VALVE LIFT Intake: 233 Exhaust: 233
Timing @ 1.00mm VALVE LIFT IVO: 10.5 BTDC EVO: 48.5 BBDC
    IVC: 42.5 ABDC EVC: 4.5 ATDC
Suggested Centre Lines:   Intake: 106 Exhaust: 112
VALVE Lift @ TDC Intake: 2.08mm Exhaust: 1.42
