ATP Turbo CHRA, GTX5018R, 85.8mm Inducer, Class Legal
by ATP Turbo
Save 10%
Original Price
$8,107.16 NZD
Current Price
$7,296.44 NZD
SKU CHRA-GTX5018R-85.8mm
Buy now pay later,no extra cost!
Payments from $729.64 with

Enjoy now. Pay Later. Interest free. Learn More




- Race class designed GTX5018R
- Special 53 Trim, 85.8 mm inducer and 117.6 mm exducer
- This turbo is built for class requirements that are limited to a 86mm compressor wheel
- Same compressor and turbine housing style as GT47 / GTX47
- Externally interchangeable with an existing GT47 and GT55 turbo setup
** CHRA ONLY **
PRODUCT SPECIFICATIONS:
* Compressor Wheel Inducer: 85.8mm
* Compressor Wheel Exducer: 117.6mm
* Compressor Wheel Trim: 53
* Turbine Wheel Inducer: 98.9mm
* Turbine Wheel Exducer: 90.6mm
* Turbine Wheel Trim: 84
APPLICABLE GARRETT PART NUMBERS:
* 769210-5038S
* 804878-5023S
CLASS LEGAL IN THE FOLLOWING RACE ORGANIZATION CATEGORIES:
** Please review class regulations for update rules and specific requirements **
